THE PRO TRADE SERIES TP96
THE PRO TRADE SERIES TP96
Everything you ever wanted in a tradesman trailer the TP96 will deliver. The largest trailer in the range, the TP96 has outstanding storage levels, additional tool drawers, an inbuilt drop saw slide providing a full-scale mobile workshop appropriate for application across many different trades. If your business needs to be organised, secure and highly mobile ensuring you can turn up to a job with everything you need then the Pro Trade Series TP96 is a must to consider.
 |
 |
BUILT TOUGH, TO PLAY TOUGH
PRO TRADE SERIES TP96
TARE 1590kg (without options)
GVM 3200kg
PAYLOAD 1600kg
BALL WEIGHT 145kg (Dry)
SIZE 4810mm(L) x 2150mm(W) x 2150mm(H)
BODY SPECIFICATION
• Heavy duty one-piece RHS chassis 100x50x4mm that’s fully hot dip galvanised and powder coated
• Precision CNC laser cut and pressed zinc anneal body sheets
• Duragal internal structure support framing
• Top storage ladder rack with welded mesh on underside and rear roller 2700mm(L) x 1800mm(W)
• Front draw bar load support rack
• Aluminium stone protection plates and foot treads all round
• Flush mount side and rear opening doors with automotive seals and gas struts
• Compression locks on all doors and storage compartments
• Fittings (bolts, nuts, washers, screws and pop rivets) are all stainless steel
RUNNING GEAR
• 8 leaf Rocket Roller suspension and solid 50mm square axles (rated 3.5 tonne)
• Dual 12” electric brake hubs with 6 stud Land Cruiser stud pattern
• 5 x 15” alloy rims and tyres
• Premium jockey wheel with rubber tyre
• 3,500kg tow coupling to suit 1 ⅞” ball with handbrake
STORAGE
• Main body storage compartment internally is 2650(L) x 1740(W) x 960(H) with lift up doors either side
• Enclosed front storage box with fridge slide, storage compartments & shelving. Fridge slide size: 850mm(L) x 550mm(W) x 530mm(H)
• Storage rail system on top of front box for additional items to be carried
• 2 x rear shelving levels, Bottom: 400mm deep, Top: 350mm deep
• 2 x massive rear slide out drawers Left side: 1530mm(L) x 640mm(W) x 360mm(H) on 160kg rated slides Right side: 2120mm(L) x 640mm(W) x 360mm(H) on 160kg rated slides
• 2 x slide out drawers either side towards front of main body 850mm(L) x 290mm(W) x 220mm(H)
• Inside is a large storage shelving platform on right side of trailer 600mm deep and full length
• 2 x toolbox style drawer systems on right side under shelf with large drawers
ELECTRICAL
• Full LED internal lighting with control management panel in main body
• 2 x 120A/H batteries
• 50 Amp Anderson Plug for charging while driving or solar (connection only)
• LED tail lights with reverse light, side marker and front clearance lights
• Safety Breakaway Unit
• Includes Elecbrake Controller
